DFB激光器
Description
大宝娱乐研制的高性能DFB激光用具有超低RIN值和高输出光功率等优点。高性能单频激光器很是适合光纤传感、光通讯、激光雷达和高精度丈量等应用。我们可凭证用户的需求提供定制效劳，并提供响应的手艺支持。
激光雷达
光通讯
微波光子
| 参数 | 符号 | 最低值 | 典范值 | 最大值 | 单位 |
| 输出功率 | Po | 40 | mW | ||
| 中心波长 | λc | 1530 | 1550 | 1560 | nm |
| 光谱线宽（FWHM） | △νc | 1 | MHz | ||
| 边模抑制比 | SMSR | 40 | dB | ||
| 偏振消光比* | PER | 20 | dB | ||
| 相对强度噪声 | RIN | -160 | -155 | dB/Hz | |
| 光隔离度 | ISO | 38 | 25 | dB | |
| 阈值电流 | Ith | 10 | mA | ||
| TEC温度设定 | TTEC | 15 | 40 | ℃ | |
| LD事情电流 | Ib | 200 | 250 | mA | |
| LD事情电压 | Vf | 1.5 | 1.8 | V | |
| PD偏压 | VR | 5 | 20 | V | |
| PD电流 | Imc | 0.1 | mA | ||
| 事情温度 | To | -40 | 25 | 80 | ℃ |
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
